Gigant Press 500 ton

• Code: ISP 1
• Manufacturer: Gigant
• Tons: 500
• Description:

  Marca/make Gigant
  Modello/model G2 500/2
  Potenza/capacity 500 ton
  Corsa /stroke 1000 mm
  Luce max tra tavole/max light between tables 1400 mm
  Luce fra i montanti/light between shoulders 2020/600 mm
  Piano/table 2000 x 1400 mm
  Mazza/ram 2000 x 1400 mm
  Nr. 4 Premilamiere/4 blankholders 250 ton
  Corsa premilamiera/blankholder's stroke 400 mm
  Dimensione tavola premilamiera/
  blankholder's table diameter 1800 x 1200 mm
  Peso/weight 43.500 kg
  Anno costruzione/year of manufacture 2001 CE
  Dimensioni ingombro/size 7000 (1000 mm under ground/interrata) x 3000 x
  1500 mm
